TSM-PC06A

Trina Solar TSM-PC06A is a multicrystalline solar module designed for residential and commercial rooftop installations. It is part of the “Honey” series and features half-cut cell technology to improve efficiency and reduce resistance.

Electrical Specifications

According to Trina Solar’s official datasheet, the module’s performance varies by specific power rating (Wp):

• Peak Power (Pmax): Available in ratings such as 260W, 265W, 270W, and 275W.
• Maximum Power Voltage (Vmpp): Ranges from 30.2V (for 260W) to 31.1V (for 275W).
• Maximum Power Current (Impp): Ranges from 8.62A to 8.85A.
• Module Efficiency: Reaches up to 16.8%.
• Power Tolerance: Guaranteed positive tolerance of 0 to +5W.

Mechanical Data

Trina Solar provides the following physical specifications for the TSM-PC06A:

• Dimensions: 1650 x 992 x 35 mm (64.96 x 39.06 x 1.38 inches).
• Weight: 18.0 kg (39.7 lb).
• Solar Cells: 120 multicrystalline cells (6 x 20 orientation).
• Glass: 3.2 mm high-transmission, AR-coated heat-tempered glass.
• Frame: Silver anodised aluminium alloy.
• Junction Box: Rated IP 67 or IP 68 for high weather resistance.
• Connector: Standard MC4 compatible.

Durability and Reliability

The module is built to withstand harsh environmental conditions:

• Load Resistance: Certified to bear snow loads up to 5400 Pa (positive load) and wind loads up to 2400 Pa (negative load).
• Environmental Resistance: Resistant to salt, acid, and ammonia, making it suitable for coastal or agricultural areas.
• Low Light Performance: Optimized cell processes ensure high energy generation during cloudy days, mornings, and evenings.
• Warranty: Typically includes a 10-year product workmanship warranty and a 25-year linear power warranty.
